The ZYT-GY01XX series are ZYTOM new ultra low power consumption Green Ethernet series, its full
load power consumption is as low as 2.16 watts. The ZYT-GY01XX switches supports a wide operating
temperature range from -40°C to 85°C. All models have IP40 protection class and
meet EMC industrial level 4 requirements.
ZYT-GY01XX series support IEEE 802.3 and IEEE802.3u with 10/100M
full/half-duplex, MDI/MDI-X auto-sensing. The ZYT-GY01XX switches provide 12~48VDC power supply. These switches are
specially designed for harsh industrial environments certified by UL508 and UL
Class 1 Div 2 certifications.
ZYT-GY01XX is a "green", embedded industrial
Ethernet module with low-power consumption. It is applicable to wind power,
subway PIS, power SCADA, sewage treatment, metallurgy, intelligent
transportation, rail transit, and many other industries.ZYT-GY01XX Embedded Ethernet Switching Module can be
directly installed in the target device.
>>Specifications
Interface
1 x Ethernet port (RJ45)
10/100Base-Tx 1 x Optical port (1x9) 100Base-Fx
Optical Port
Available for 1310nm and
1550nm Single mode, and 1310nm Multi mode
Transfer Distance: up to 120km
Connectors: SC/PC, ST/PC, optional
Fiber core: 8.3μm, 8.7μm, 9μm and 10μm on
single-mode fiber; 50, 62.5 and 100μm on multi-mode fiber
Ethernet Port
Standard: IEEE802.3, IEEE802.3u, IEEE802.3x
Available speed: force 10Mbps, force 100Mbps and auto-detective
10/100Mbps Full-Duplex and Half-Duplex auto-negotiation
Connectors: RJ-45 Connector;
MDI/MDI-X connection auto-sensing
Switch Properties
MAC Table: 2K
Packet Buffer: 1Mbit
Switching Delay: <5μs
LED Indicators
Power, Status, Speed, FX Link/Act, TX Link/Act
Power Requirement
Input: 12VDC~48VDC
Consumption 3.5W
Overload Protection:： Support
Reverse Connection Protection: Support
Redundancy Protection: Support
Physical Characteristics
Housing: Metal enclosure
Protection Class: IP40
Dimensions: 48 x 104 x 143mm
Weight: 0.4kg
Installation: DIN-Rail or Panel mounting
Environmental Limits
Operating Temperature: -40°C to 85°C
Storage Temperature: -40°C to 85°C
Operating Humidity: 10% to 95% RH (non-condensing)
Storage Humidity: 5% to 95% RH (non-condensing)
Agency Approvals
FCC Part 15 of Class A & CE approved
Industrial Standard
EMI: FCC/CE/LVD/EMC EMS:
IEC61000-4-2(ESD): ±8kV (contact), ±15kV (air)
IEC61000-4-3(RS): 10V/m (80MHz-2GHz)
IEC61000-4-4(EFT): Power Port: ±4kV; Data Port: ±2kV
IEC61000-4-5(Surge): Power Port: ±2kV/DM, ±4kV/CM;
Data Port: ±2kV
IEC61000-4-6(CS): 3V (10kHz-150kHz); 10V (150kHz-80MHz)
IEC61000-4-16(Common mode conduction): 30V (cont.), 300V (1s)
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Warranty
5 years
